OUTPUT
Voltage - 12V
Rated Current - 5A
Rated Power - 60W
Efficiency (Typ.) - >85%
Ripple & Noise - <120mVp-p
Voltage Tolerance - ±2%
Line Regulation - ±2%
Load Regulation - ±2%
Output Channel - 1 channel
INPUT
Voltage Range - 100 - 240VAC
Frequency Range - 50 - 60Hz
PROTECTION
Input - 3A / 250VAC fuse
Short Circuit - Hiccup mode, recovers automatically after fault condition is removed.
ENVIRONMENT
Working Temperature - -20 - 50?
Working Humidity - 20 - 80%RH
Storage Temperature - -30 - 80?
Storage Humidity - 10 - 90%RH
SAFETY & EMC
EMC Standards EN 55022: 2010, EN 55024: 2010, EN 61000-3-2: 2014, EN 61000-3-3: 2013
LVD Standards EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013
CABLE
Output Length - 1000mm
Output Diameter - 20AWG
Input Length - 500mm
Input Diameter - 20AWG
Product Dimension - 108 x 60 x 35mm
