PHYSICAL
Size (HxWxD): 96x53x59 ±0.5 mm / 3.78x2.01x2.32 ±0.02 in
Weight: 0.150 kg
Mounting: DIN rail
Screw terminals max torque: 0.4 Nm / 4.43 lbin
Conductor cross section: 0.5 to 2.5 mm² / 20 to 14 AWG
Conductor stripped length: 6 to 7 mm / 0.24 to 0.28 in
Shell material: Plastic
Color: Black
ENVIRONMENTAL
Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F
Humidity: 30 % to 70 % RH
Max. altitude: 2000 m / 6562 ft
ELECTRICAL
Power supply voltage AC: 110 - 240 V
Power supply voltage DC: N/A
Power consumption: < 3 W
Neutral not needed: No
OUTPUT CIRCUITS RATINGS
Max switching voltage AC: 240 V
Max switching voltage DC: 30 V
Max switching current AC: 16 A per channel, 48 A total
Max switching current DC: 16 A per channel, 48 A total
SENSORS, METERS
Temperature sensor: Yes
RADIO
RF band: 24010- 2495 MHz
Max. RF power: <20 dBm
Wi-Fi protocol: 802.11 b/g/n
Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol: 4.2
Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
MCU
CPU: ESP32-D0WDQ6
Flash: 8 MB
FIRMWARE CAPABILITIES
Schedules: 20
Webhooks (URL actions): 20 with 5 URLs per hook
Scripting: mJS
MQTT: Yes
CoAP: No
