POWER
Power supply AC No
Power supply DC 12-24V
DC Power Output 12V per channel 45W
DC Power Output 24V per channel 90W
DC Power Output 12V combined power 144W
DC Power Output 24V combined power 288W
SPECIAL FUNCTIONS
Device temperature protection No
Overload protection No
Power measurement Yes
Dimming Yes
Working without a neutral line No
FEATURES
Color changing Yes
Predefined effects Yes
Channels 4 Channels
Maximum load 12A
Operational temperature 0?C to 40?C
Device power consumption < 1 W
Intelligent On/Off Yes
Local and remote control Yes
Sunrise/Sunset Yes
Weekly Schedule Yes
UL Listed option No
CONNECTIVITY
Wireless/WiFi Protocol 802.11 b/g/n
Radiofrequency 2400 – 2500 MHz
Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
DIMENSIONS
Size 43mm x 38mm x 14mm
