Screen size: IPS 10.1 inch screen,1280*800 capacitive touch screen
Display: HDMI 4K@30fps
Decoding capability: Max.H.264 1CH 1080p@60fps / 4CH 720p@30fps / Max.H.265 1CH 4k@30fps
Protocol: ONVIF 2.4
Function: Up to 1024 devices to be added; PTZ Control; Calling or setting preset, cruise, scan, etc.
System settings: Supports language settings, password modification and USB flash disk upgrade
Power: Standard 5.5/2.1 Power interface, DC 12V2A±10%
Interfaces: 1 - RJ45 Ethernet port; 1 - RS485; 1 - RS232; 1 - HDMI output(V 1.3); 1 - USB2.0 port; 1 - standard 3.5mm headphone jack
Operation interface: 4D Joystick, Buttons
Power consumption: <15W
Standby current: <100mA
Mean time between failures: >30000
Working humidity: 10%-90%(RH)
Working temperature: -10°C-40°C
Storage temperature: -40°C-60°C
Dimensions(mm): 445x179x118
Net weight(kg): Approx. 1.388
